VYOM X1

About VYOM X1

Overview:

Vyom X1 is engineered for endurance and operational flexibility, integrating a multirotor-based lift system with a fixed-wing pusher configuration for efficient long-distance flight. The UAV employs a redundant architecture with industrial-grade sensors, including RTK-enabled GNSS, redundant IMU, and pitot-based airspeed sensing. These systems ensure precision in flight control and stability across diverse environmental conditions.

The UAV s communication systems utilize frequency hopping spread spectrum (FHSS) technology for secure and interference-resistant data transmission. Video feed and telemetry operate effectively within 20 kilometers LOS, with an optional module enabling extended telemetry coverage up to 100 kilometers.

Specification	Details
Dimensions	Length: 1450 mm, Wingspan: 2430 mm, Height: 180 mm
Max Take-Off Weight	12 kg
VTOL Mechanism	Puller quadcopter configuration with puller transition
Power System	4 Electric Motors (VTOL) + 1 Electric Puller Motor
Battery	Customised for endurance
Endurance	>120 minutes (with 500g load), up to 140 minutes (no load)
Speed	Max: 22 m/s, Cruise: 17 19 m/s, Stall: 11 m/s
Service Ceiling	5000 metres MSL
Wind Resistance	Up to 5 m/s
Autopilot System	STM32H7 Processor with redundant triple IMU sensors
Navigation System	High-precision redundant RTK GNSS (protected frequencies)
Optional Navigation	Radar-based velocity system for GPS-denied environments (up to 1 km range)
Payload Capacity	Up to 2 kg
Camera Resolutions	4K (4096 2160) @ 25 fps, 2K (2560 1440) @ 30 fps, 1080p, 720p
Camera Angles	Pitch: -135 to +45, Yaw: -160 to +160, Roll: -30 to +30
Lens	Fixed focal length, 6 Digital Zoom
Controller Specs	Weight: 850g, 16 channels, 7.4V, 10200mAh, 8 hours endurance
Controller Frequency	2.4GHz 2.483GHz
Communication	FHSS; Data Range: 20 30 km LOS, Video Range: 8 10 km LOS
Controller Waterproofing	IP53
Optional Telemetry	840 845 MHz; up to 100 km; Frequency Hopping, GMSK, 2GFSK, 4GFSK, QPSK

Notable Features:

- VTOL with compact puller-quadcopter mechanism

- Fixed-wing endurance exceeding 120 minutes with light payload

- High-precision redundant RTK GNSS and industrial-grade autopilot system

- Optional radar-based velocity navigation for GPS-denied environments

- Robust communication range up to 100 km with optional telemetry module

- Secure, frequency-hopping FHSS technology for reliable data transmission

- High-resolution imaging with 4K/2K/1080p/720p and 6X digital zoom

- IP53-rated water-resistant controller with 8-hour endurance

Comprehensive Surveillance with Flexible Installation

The VYOM X1 PTZ Dome Camera brings full-range monitoring with its 355 pan and 90 tilt capabilities, enabling users to cover broad areas from a single installation point. Designed for both ceiling and wall mounting, it seamlessly adapts to a wide variety of spaces, ensuring a discreet yet comprehensive security setup for homes and businesses in Iran.


Crystal Clear Footage Day & Night

Equipped with a 2MP CMOS sensor and 3.6mm lens, the VYOM X1 captures high-definition 1080p video with exceptional clarity. Six powerful IR LEDs ensure effective night vision up to 15 meters, maintaining reliable monitoring under low-light or complete darkness, making it ideal for round-the-clock indoor and outdoor use.


Smart Features & Effortless Control

Benefit from intelligent motion detection, real-time push alerts, and two-way audio interaction through the built-in microphone and speaker. With dedicated Android and iOS app support, users can access live footage, receive alerts, and control the camera remotely from anywhere, enhancing confidence in security management.
